Swing Gate Turnstile
Created with Pixso. Swing Gate Turnstile With Facial Recognition For Office Building Entrance Attendance

Swing Gate Turnstile With Facial Recognition For Office Building Entrance Attendance

Brand Name: Kemaisi
Model Number: KMS-Z8621
MOQ: 1 pcs
Price: USD560-USD1100
Delivery Time: 5-14 work days
Payment Terms: T/T
Detail Information
Place of Origin:
Guang Dong China
Certification:
CE | RoHS
Product Name:
Swing Turnstile
Passage Frame:
304 Stainless Steel / 201 Stainless Steel With Baked Paint
Product Size:
1400mm*160mm*1000mm
Channel Width:
550mm-1000mm
Product Power:
100W
Infrared Sensor:
4 Pairs
Packaging Details:
Wooden Case Package
Supply Ability:
1000peices/Month
Highlight:

Swing Gate Turnstile with facial recognition

,

Office building entrance attendance turnstile

,

Swing Gate Turnstile for secure access

Product Description
Swing Gate Turnstile With Facial Recognition For Office Building Entrance Attendance
Product Overview

Office buildings experience heavy foot traffic daily. Traditional access cards are easily lost, creating security risks, while attendance records require manual export from punch clocks, consuming significant administrative time. This intelligent turnstile achieves "passage as attendance" - automatically recording clock-in and clock-out times when employees enter or exit. Managers can generate complete attendance reports with a single click from the backend.

The device supports facial recognition for passage, eliminating the need for employees to carry cards and completely removing the risk of card loss. Built-in fault self-diagnosis and alarm functions simplify daily maintenance. Operating status can be programmed on-site via the built-in keypad on the main control board, flexibly adapting to different management needs.

In power failure situations, the turnstile triggers fire mode, sounds an alarm, and automatically opens the gate, ensuring unobstructed emergency evacuation. The system also features an automatic reset function: if no passage occurs within the set time after gate opening (default 10 seconds), the current permission is automatically cancelled, preventing tailgating or misuse. This turnstile is a reliable solution for improving office building passage efficiency and security.

Key Features & Advantages
Passage as Attendance, One-Click Report Export

The system automatically records clock-in and clock-out times when employees enter or exit. Attendance data can be generated with a single click from the backend, eliminating the need for administrators to compile daily statistics and greatly improving work efficiency. Supports facial recognition verification - employees can pass using facial recognition, completely eliminating security risks and card replacement hassles caused by lost access cards.

Fault Self-Diagnosis and Alarm

Built-in self-diagnosis module triggers automatic alarms when abnormalities occur, helping maintenance staff quickly locate problems and reduce equipment downtime. Via the built-in keypad on the main control board, turnstile operating parameters can be flexibly programmed on-site to meet passage logic needs for different time periods or special events.

Automatic Door Opening on Power Failure for Fire Safety

In power failure situations, the turnstile triggers fire mode, sounds an alarm, and automatically opens the gate, ensuring rapid evacuation and compliance with fire safety regulations.

Automatic Reset to Prevent Tailgating

If no one passes within 10 seconds after the gate opens, the system automatically cancels the current permission, requiring re-verification. This effectively prevents a single authorization from being exploited for tailgating or wasted unintentionally.

Technical Specifications
Product NameSwing Turnstile
Barrier MaterialAcrylic Swing Arm
Passage Frame304 Stainless Steel / 201 Stainless Steel With Baked Paint
Product Size1400*160*1000mm (Sizes Can Be Customized)
Traffic Speed30 People/Minute, Normally Open 40 People/Minute
Service Life≥5 Million Times
Channel Width550-1000mm
Working VoltageAC220V±10%/50HZ 50W
Relative Temperature≤95% Not Condensing
Product Power100W
Weight40-65KG
Opening Time0.5 Seconds
Ambient Temperature-30℃-70℃
LED Indicator Lights2
Work EnvironmentIndoor and Outdoor
Protection GradeIP43, IP54
Infrared Sensor4 Pairs
Access Control TypeRFID/IC/ID card. Face/Iris recognition/Fingerprint identification. QR code. Mobile phone/NFC. Password. Remote door opening
Communication InterfaceRelay switch signal/12V level signal/12V pulse signal with pulse width>100ms; RS485 or TCP/IP
Swing Gate Turnstile with facial recognition system for office building entrance
Frequently Asked Questions
Q1: What is a full height turnstile gate?

A full height turnstile gate is a high-security pedestrian access control barrier that uses full-height rotating arms to prevent unauthorized entry. It is commonly used in places requiring strict security management.

Q2: What is the difference between a full height turnstile and a tripod turnstile?

A tripod turnstile only controls access at waist height, while a full height turnstile provides a complete barrier that prevents climbing over or bypassing, making it more suitable for high-security environments.

Q3: Can this turnstile work with facial recognition systems?

Yes. The full height turnstile supports integration with facial recognition, fingerprint scanners, RFID readers, QR code systems, and other access control technologies.

Q4: Is this turnstile suitable for outdoor use?

Yes. With a durable stainless steel structure and weather-resistant design, it can be installed in outdoor environments such as stadium entrances, factories, and construction sites.

Q5: How many people can pass through the turnstile?

The traffic capacity depends on the model and access management settings. It is designed for continuous pedestrian flow in high-volume applications.

Q6: Does the turnstile support emergency opening?

Yes. The system can be connected with fire alarm systems and emergency controls to allow rapid evacuation when required.

Why Choose Our Full Height Turnstile Gate?

Choosing the right pedestrian security gate is essential for protecting your facility. Our full height turnstile system combines mechanical strength, smart access control compatibility, and reliable performance to deliver a professional security entrance solution.

Whether you need access control for a factory, stadium, government building, transportation station, or restricted facility, this high-security turnstile provides an effective way to manage pedestrian access.

Request a Free Quote

Looking for a reliable full height turnstile gate supplier? Contact us today for:

  • Free product consultation
  • Customized access control solutions
  • Competitive factory pricing
  • Technical support
  • Project-based recommendations

Request your free quote now and improve your facility security with our professional full height turnstile access control system.

Full height turnstile gate installation and application examples
