| Brand Name: | Kemaisi |
| Model Number: | KMS-T525 |
| MOQ: | 1 pcs |
| Price: | USD560-USD1100 |
| Delivery Time: | 5-14 work days |
| Payment Terms: | T/T |
In places such as technology companies , large and medium sized office buildings , high end communities , and smart campuses , traditional access cards are easily lost , creating security risks . Attendance records also need to be manually exported from punch clocks , and administrative staff spend significant time and effort on statistics . This intelligent turnstile achieves “ passage as attendance ” – the system automatically records clock in and clock out times the moment employees enter or exit , and managers can generate a complete attendance report with a single click from the backend . The device supports facial recognition for passage , so employees do not need to carry any card , completely eliminating the risk of card loss . The gate opening and closing speed is adjustable according to the passage width ( from 0 . 3 seconds to 1 second for a passage width of 600 mm to 1500 mm ) , ensuring efficient and smooth passage . Built in passage light indicators : a green light indicates that passage is allowed , while a red light indicates that passage is prohibited , guiding people through in an orderly manner . This turnstile integrates mechanical , electronic , microprocessor control , and various identification technologies . It is compatible with card readers for IC cards , ID cards , barcode cards , fingerprints , and more , and optional modules such as safety protection , alarms , and direction indicators can be added to achieve intelligent passage control . It is a reliable choice for improving office building passage efficiency and security management levels .
The system automatically records clock in and clock out times the moment employees enter or exit . Attendance data can be generated with a single click from the backend . Administrators do not need to compile daily statistics , greatly improving work efficiency . Supports facial recognition verification – employees can pass by using facial recognition , completely eliminating the security risks and card replacement hassle caused by lost access cards .
The gate opening and closing speed is adjustable : for a passage width of 600 mm to 1500 mm , the opening time ranges from 0 . 3 seconds to 1 second , balancing safety and efficiency . Wide passages require confirmation in advance .
The turnstile is equipped with red and green indicator lights : a green light allows passage , a red light prohibits passage , clearly guiding people through the turnstile in an orderly manner and reducing wrong way entry .
Integrates mechanical , electronic , and microprocessor control technologies . Compatible with card readers for IC cards , ID cards , barcode cards , fingerprints , and more . Optional modules such as safety protection , alarms , and direction indicators can be added , flexibly meeting the intelligent upgrade needs of different scenarios .
| Product Name | Speed gate |
| Barrier Material | Acrylic Swing Arm |
| Passage Frame | 304 Stainless Steel / 201 Stainless Steel With Baked Paint |
| Product Size | 168*1050mm (Sizes Can Be Customized) |
| Traffic Speed | 30 People/Minute, Normally Open 40 People/Minute |
| Service Life | ≥5 Million Times |
| Channel Width | 600-1500mm |
| Working Voltage | AC220V±10%/50HZ 50W |
| Relative Temperature | ≤95% Not Condensing |
| Product Power | 80W |
| Opening Time | 0.5 Seconds |
| Ambient Temperature | -30℃-70℃ |
| Work Environment | Indoor And Outdoor |
| Protection Grade | IP43, IP54 |
| Infrared sensor | 1 Pairs |
| Access Control Type | RFID/IC/ID card. Face/Iris recognition/Fingerprint identification.QR code. Mobile phone/NFC. Password. Remote door opening |
| Communication Interface | Relay switch signal/12V level signal/12V pulse signal with pulse width＞100ms; RS485 or TCP/IP |
Yes. The speed gate fully supports facial recognition terminals and can also integrate RFID cards, QR codes, fingerprints, NFC, and mobile access systems.
Yes. Standard passage width ranges from 600 mm to 900 mm, with wider lanes available for wheelchair or luggage access.
Yes. Outdoor versions with enhanced waterproof protection (IP65 optional) are available for semi-outdoor and outdoor environments.
Yes. The gate supports TCP/IP, RS485, Wiegand, Dry Contact, and API integration, making it compatible with most mainstream access control software.
Absolutely. We offer full OEM & ODM customization, including cabinet dimensions, colors, branding, access modules, software integration, and packaging.
