| Brand Name: | Kemaisi |
| Model Number: | KMS-Y718 |
| MOQ: | 1 pcs |
| Price: | USD350-USD700 |
| Delivery Time: | 5-14 work days |
| Payment Terms: | T/T |
For cleanrooms that manufacture precision instruments , static electricity carried by employees can reach several thousand volts . When they come into contact with precision components , it can cause invisible damage , leading to lower product yields , customer claims , and other serious consequences . Traditional workshops only put up a sign at the entrance saying “ please touch the static discharge ball ” . Employees who are in a hurry or simply forget walk straight in – the measure becomes ineffective . Kemaisi ‘ s latest anti static wing barrier completely changes this situation . It forces employees to use the electrostatic test pad next to the turnstile . Only when the static reading is within the acceptable range will the turnstile open , physically preventing non compliant personnel from entering the workshop . At the same time , it integrates facial recognition and attendance functions . The employee stands on the test pad facing the recognition terminal , and the system automatically completes identity verification , static detection , and records clock in and overtime hours – one stop passage . If the static test fails , the turnstile remains locked and a voice prompt says : “ Static excessive – please use the static discharge ball ” . The employee presses the static discharge ball placed next to the turnstile for 3 to 5 seconds , then takes the test again . If the result is now acceptable , passage is granted . The system automatically records for each passage : employee ID , time , static test value , pass or fail result , and whether the static discharge ball was used . The quality department can retrieve reports at any time for customer complaint tracking , internal audits , and continuous improvement . This anti static wing barrier is an ideal closed loop solution for static control in cleanrooms .
Employees must use the electrostatic test pad next to the turnstile , and only when the static value is acceptable will the turnstile open . Those who fail cannot enter , physically preventing non compliant personnel from entering the workshop and completely eliminating the risk of static damage .
The employee stands on the test pad facing the facial recognition terminal . The system automatically verifies identity , detects the static value , and simultaneously records clock in time and overtime hours – one stop passage , saving time and effort , without the need for multiple operations .
When the test fails , the turnstile remains locked and a voice prompt says : “ Static excessive – please use the static discharge ball ” . A static discharge ball can be placed next to the turnstile . The employee presses it for 3 to 5 seconds and then takes the test again . If the result is now acceptable , passage is granted , forming a complete closed loop solution .
The system automatically records for each passage : employee ID , time , static test value , pass or fail result , and whether the static discharge ball was used . The quality department can retrieve reports at any time for customer complaint tracking , internal audits , and continuous improvement .
| Product Name | Wing Gate |
| Barrier Material | Acrylic Swing Arm |
| Passage Frame | 304 Stainless Steel / 201 Stainless Steel With Baked Paint |
| Product Size | 1200mm*300mm*980mm (Sizes Can Be Customized) |
| Traffic Speed | 30 People/Minute, Normally Open 40 People/Minute |
| Service Life | ≥5 Million Times |
| Channel Width | 550-600mm |
| Weight | 50-85KG |
| LED indicator | 2 pieces |
| Working Voltage | AC220V±10%/50HZ 50W |
| Relative Temperature | ≤95% Not Condensing |
| Product Power | 100W |
| Opening Time | 0.5 Seconds |
| Ambient Temperature | -30℃-70℃ |
| Work Environment | Indoor And Outdoor |
| Protection Grade | IP43, IP54 |
| Infrared Sensor | 6 Pairs |
| Access Control Type | RFID/IC/ID card. Face/Iris recognition/Fingerprint identification.QR code. Mobile phone/NFC. Password. Remote door opening |
| Communication Interface | Relay switch signal/12V level signal/12V pulse signal with pulse width＞100ms; RS485 or TCP/IP |
An ESD swing gate is an intelligent access control system that combines electrostatic discharge testing with a pedestrian swing barrier. Personnel must pass ESD testing before entering an Electrostatic Protected Area (EPA).
Yes. The system supports face recognition, RFID cards, fingerprints, QR codes, and other authentication methods.
Yes. The wrist strap resistance range and footwear resistance thresholds can be configured according to your company's ESD requirements.
Yes. The turnstile supports TCP/IP, RS485, Wiegand, and can be integrated with attendance systems, access control software, MES, ERP, and third-party platforms.
Yes. We provide OEM and ODM services, including logo customization, housing design, software development, communication protocols, and project-based solutions.
