| Brand Name: | Kemaisi |
| Model Number: | KMS-B8502 |
| MOQ: | 1 pcs |
| Price: | USD560-USD1100 |
| Delivery Time: | 5-14 work days |
| Payment Terms: | T/T |
In scenarios such as technology companies , large and medium sized office buildings , high end communities , and smart campuses , traditional access cards are easily lost , creating security risks . Attendance data needs to be manually exported from punch clocks or access control systems , and administrative staff spend significant time and effort on statistics . This intelligent turnstile achieves “ passage as attendance ” – each time employees enter or exit , the system automatically records clock in and clock out times , and managers can generate a complete attendance report with a single click from the backend . The device supports two in one facial recognition and card swiping , allowing employees to pass using facial recognition , completely eliminating the need for physical cards . Built in fault self diagnosis and alarm functions make daily maintenance simple . The operating status can be programmed on site via the built in keypad on the main control board . The main board is equipped with an LCD screen that supports multiple languages , making operation intuitive . In the event of a power failure , the turnstile automatically triggers fire mode , sounds an alarm , and opens the gate , ensuring safe evacuation . The memory function accurately records the number of consecutive card swipes and the number of people passing , greatly improving passage efficiency during peak hours . It also supports password remote locking and features audible and visual alarms for unauthorised entry and tailgating , providing comprehensive passage security .
The system automatically records clock in and clock out times the moment employees enter or exit . Reports can be exported with a single click from the backend . Administrators do not need to compile daily statistics , greatly improving attendance management efficiency .
Supports two verification methods : facial recognition and card swiping . Employees can pass using facial recognition , eliminating the security risks and inconvenience caused by lost access cards .
Built in self diagnosis module triggers an automatic alarm when an abnormality occurs , helping maintenance staff quickly locate problems and reducing downtime . Via the built in keypad on the main control board , turnstile operating parameters can be flexibly programmed on site to meet management needs in different scenarios .
The main board is equipped with an LCD screen that supports switching between multiple languages . Parameter settings are intuitive and convenient , adapting to international or diverse personnel environments .
In the event of a power failure , the turnstile triggers fire mode , sounds an alarm , and automatically opens the gate , ensuring unobstructed emergency evacuation of people and complying with fire safety regulations .
During continuous card swiping , it accurately remembers the number of swipes and the number of people passing , avoiding repeated authorisation . Passage becomes smoother during peak hours .
Supports password setting and remote locking of the turnstile , preventing operation during unauthorised periods or by unauthorised personnel , enhancing management flexibility .
Unauthorised entry or tailgating immediately triggers an audible and visual alarm , effectively deterring violators and ensuring entrance order and security .
| Product Name | Swing Turnstile |
| Barrier Material | Acrylic Swing Arm |
| Passage Frame | 304 Stainless Steel / 201 Stainless Steel With Baked Paint |
| Product Size | 1400mm*150mm*1000mm (Sizes Can Be Customized) |
| Traffic Speed | 30 People/Minute, Normally Open 40 People/Minute |
| Service Life | ≥5 Million Times |
| Channel Width | 550mm-1000mm |
| Working Voltage | AC220V±10%/50HZ 50W |
| Relative Temperature | ≤95% Not Condensing |
| Product Power | 100W |
| Weight | 40-65KG |
| Opening Time | 0.5 Seconds |
| Ambient Temperature | -30℃-70℃ |
| LED indicator lights | 2 |
| Work Environment | Indoor And Outdoor |
| Protection Grade | IP43, IP54 |
| Infrared sensor | 4 Pairs |
| Access Control Type | RFID/IC/ID card. Face/Iris recognition/Fingerprint identification.QR code. Mobile phone/NFC. Password. Remote door opening |
| Communication Interface | Relay switch signal/12V level signal/12V pulse signal with pulse width＞100ms; RS485 or TCP/IP |
Yes. It supports TCP/IP, RS485, Wiegand, API, and SDK integration, ensuring compatibility with most third-party access control platforms.
Yes. An IP65-rated outdoor version is available for installations requiring enhanced weather resistance.
The gate supports Face Recognition, RFID Cards, QR Codes, Fingerprint, NFC, Mobile App Access, and optional Bluetooth credentials.
Yes. We provide OEM and ODM services, including custom dimensions, cabinet finishes, branding, authentication devices, and software integration.
The barriers automatically unlock, allowing safe pedestrian evacuation in compliance with international fire safety requirements.
