| Brand Name: | Kemaisi |
| Model Number: | KMS-B8613 |
| MOQ: | 1 pcs |
| Price: | USD650-USD1300 |
| Delivery Time: | 5-14 work days |
| Payment Terms: | T/T |
Office buildings receive many visitors every day . Traditional manual registration at the front desk is not only inefficient but also leaves an unprofessional impression on visitors . Temporary visitor cards are often at risk of being lost , creating security hazards . This intelligent turnstile enables a completely paperless visitor passage : visitors make an online reservation and receive a dynamic QR code , then scan the code to pass through the turnstile , with no front desk intervention . The system grants passage permissions strictly according to the reserved time slot , and expired QR codes automatically become invalid , effectively enhancing the security level . Employees and regular occupants can also choose to pass by scanning a QR code , completely eliminating the need for physical cards . The device has built in fault self diagnosis and alarm functions for easy daily maintenance . The operating status can be programmed on site via the built in keypad on the main control board . The main board is equipped with an LCD screen that supports multiple languages , making parameter settings intuitive and fast . In the event of a power failure , the turnstile automatically triggers fire mode , sounds an alarm , and opens the gate , ensuring unobstructed emergency evacuation of people . This turnstile is an ideal choice for improving office building management efficiency and professional image .
Visitors make an online reservation and receive a dynamic QR code , then scan the code to pass through the turnstile , completely replacing manual front desk registration and temporary cards , enhancing reception efficiency and the company ‘ s professional image .
Passage is only allowed during the reserved time slot . Expired QR codes automatically become invalid , eliminating overtime stays or unauthorised entry , significantly strengthening the security level . Visitors and employees can directly scan a QR code to pass , saving the cost of issuing , recycling , and maintaining physical cards , and reducing the risk of card loss .
Built in self diagnosis module triggers an automatic alarm when an abnormality occurs , helping maintenance staff quickly locate problems and reducing equipment downtime . Via the built in keypad on the main control board , turnstile operating parameters can be flexibly programmed on site to meet management needs for different time periods or special events . The main board is equipped with an LCD screen that supports switching between multiple languages , making parameter settings intuitive and convenient , adapting to international office environments or different operators .
In the event of a power failure , the turnstile triggers fire mode , sounds an alarm , and automatically opens the gate , ensuring unobstructed emergency evacuation of people and complying with fire safety regulations .
| Product Name | Swing Turnstile |
| Barrier Material | Acrylic Swing Arm |
| Passage Frame | 304 Stainless Steel / 201 Stainless Steel With Baked Paint |
| Product Size | 1200mm*160mm*1000mm (Sizes Can Be Customized) |
| Traffic Speed | 30 People/Minute, Normally Open 40 People/Minute |
| Service Life | ≥5 Million Times |
| Channel Width | 550mm-800mm |
| Working Voltage | AC220V±10%/50HZ 50W |
| Relative Temperature | ≤95% Not Condensing |
| Product Power | 100W |
| Weight | 40-65KG |
| Opening Time | 0.5 Seconds |
| Ambient Temperature | -30℃-70℃ |
| LED indicator lights | 2 |
| Work Environment | Indoor And Outdoor |
| Protection Grade | IP43, IP54 |
| Infrared sensor | 4 Pairs |
| Access Control Type | RFID/IC/ID card. Face/Iris recognition/Fingerprint identification.QR code. Mobile phone/NFC. Password. Remote door opening |
| Communication Interface | Relay switch signal/12V level signal/12V pulse signal with pulse width＞100ms; RS485 or TCP/IP |
Yes. It supports facial recognition, RFID cards, QR codes, fingerprint readers, NFC, and other third-party authentication devices.
Yes. Standard passage widths range from 600 mm to 900 mm, with wider accessible lanes available for wheelchair users and luggage.
Yes. An IP65-rated outdoor version is available for semi-outdoor and outdoor environments.
The gate supports TCP/IP, RS485, Wiegand, Dry Contact, and API integration, ensuring compatibility with most access control systems.
Yes. We offer full customization, including dimensions, cabinet colors, branding, software integration, and packaging.
