| Brand Name: | Kemaisi |
| Model Number: | KMS-G6545 |
| MOQ: | 1 pcs |
| Price: | USD470-USD940 |
| Delivery Time: | 5-14 work days |
| Payment Terms: | T/T |
QR Code Recognition Anti-Tailgating Tripod Turnstile for Paperless Cinema Entry
Product Description
Cinemas and theaters have long relied on ushers tearing tickets by hand, which pushes up labor costs. During holiday peaks the queues grow so long that audiences miss the start of the show, badly hurting the viewing experience. The Kemaisi QR code recognition tripod turnstile enables fully paperless passage: after buying a ticket on the app, viewers simply scan the QR code at the gate for instant entry. The whole process is self-service, with no ticket checker at the lane, which completely frees up manpower and fits 24/7 unattended operation. Each QR code can be scanned only once and carries anti-copy properties, eliminating ticket fraud at the source and protecting ticket revenue. The device also includes anti-tailgating and anti-crash functions that accurately detect unauthorised following and trigger alarms, keeping passage orderly and secure. The turnstile mechanism uses a unique mechanical structure that runs smoothly and reliably with low noise and a long service life. On a power failure the gate automatically unlocks and switches to mechanical free-passage mode, ensuring unobstructed emergency evacuation and fully complying with fire evacuation requirements. It suits cinemas, theaters, stadiums, exhibition halls and other unattended ticketed venues.
Product Advantages
1. Self-service QR code passage, completely freeing up manpower costs
Viewers buy tickets on their phones and scan the code to enter directly, with no manual verification at any step. No ticket checkers are needed at the lane, making it ideal for 24-hour unattended cinemas and late-night sessions while significantly reducing operating costs.
2. Single-use anti-copy QR code, eliminating ticket fraud
Each QR code is valid for a single scan and carries financial-grade anti-copying properties. Screenshots are unusable, one ticket is valid for one person and becomes invalid after scanning, technically preventing ticket reuse, screenshot forgery and scalping, firmly securing ticket revenue.
3. Anti-tailgating and anti-crash, ensuring passage security
Built-in infrared sensors accurately detect tailgating and trigger alarms, while the robust body resists impact and prevents forced entry, keeping passage orderly, protecting equipment and reducing manual intervention.
4. Smooth low-noise mechanism, creating an immersive viewing atmosphere
The internal mechanism uses a unique mechanical design that runs smoothly with extremely low noise, without disturbing the quiet viewing environment. It maintains excellent performance under high-frequency start-stop cycles with an ultra-long service life, significantly reducing maintenance costs.
5. Automatic gate opening on power failure, worry-free fire evacuation
On a sudden power failure the gate automatically unlocks and switches to mechanical free-passage mode, fully opening the lane so viewers can evacuate rapidly and unobstructed in an emergency, fully complying with fire safety regulations.
Specifications
| Product Name | cinema Tripod Turnstile |
| Barrier Material | 304 Stainless Steel / 201 Stainless Steel With Baked Paint |
| Passage Frame | 304 Stainless Steel / 201 Stainless Steel With Baked Paint |
| Product Size | 400mm*330mm*1100mm (Sizes Can Be Customized) |
| Traffic Speed | 30 People/Minute, Normally Open 40 People/Minute |
| Service Life | ≥5 Million Times |
| Channel Width | 550-600mm |
| Rotation angle per step | 120° |
| Working Voltage | AC220V±10%/50HZ 50W |
| Relative Temperature | ≤95% Not Condensing |
| Product Power | 50W |
| Opening Time | 0.5 Seconds |
| Ambient Temperature | -30℃-70℃ |
| Work Environment | Indoor And Outdoor |
| Protection Grade | IP43, IP54 |
| Access Control Type | RFID/IC/ID card. Face/Iris recognition/Fingerprint identification.QR code. Mobile phone/NFC. Password. Remote door opening |
| Communication Interface | Relay switch signal/12V level signal/12V pulse signal with pulse width>100ms; RS485 or TCP/IP |
FAQ
Q1: How does QR code recognition entry work?
A: Audiences purchase tickets through the app or mini program, then simply scan the QR code at the turnstile for self-service entry. No ticket checker is required at the lane, making it suitable for 24/7 unattended operation.
Q2: Can a QR code be reused or copied as a screenshot?
A: No. Each QR code is valid for a single scan and carries financial-grade anti-copying properties. Screenshots are unusable and the code becomes invalid after scanning, which prevents ticket reuse and fraud.
Q3: Does it prevent people from tailgating through the lane?
A: Yes. Built-in infrared sensors accurately detect tailgating and trigger an alarm, and the robust body resists impact to prevent forced entry.
Q4: What happens to the gate during a power failure?
A: On a sudden power failure the arms automatically unlock and switch to mechanical free-passage mode, keeping the lane open for rapid evacuation and meeting fire safety requirements.
Q5: What is the minimum order quantity and the delivery time?
A: The minimum order quantity is 1 pcs. Delivery time is 5-14 working days, with a monthly supply ability of about 1000 pieces.
