| Brand Name: | Kemaisi |
| Model Number: | KMS-Y7501 |
| MOQ: | 1 pcs |
| Price: | USD560-USD1100 |
| Delivery Time: | 5-14 work days |
| Payment Terms: | T/T |
This wing barrier is a CE certified stainless steel access control turnstile built for offices, commercial buildings, factories and public entrances where certified quality and reliable pedestrian access control are essential. The full product range is CE and RoHS certified and complies with the safety, EMC and material requirements of the European market, so it can be delivered to EU projects without additional compliance risk. The 304 stainless steel passage frame with baked paint finish is corrosion resistant and durable, and the unit offers IP43 and IP54 protection grades for both indoor and outdoor installation. It integrates mechanical, electronic and microprocessor control and supports multiple identification technologies including RFID, IC and ID cards, fingerprint, QR code, NFC and face recognition. Six pairs of infrared sensors detect pedestrians precisely, the opening time is only 0.5 seconds, and the traffic speed reaches 30 people per minute (40 people per minute in normally open mode), making it an ideal certified access control solution for overseas projects.
The turnstile is CE certified and RoHS compliant, meeting European safety, EMC and hazardous substance requirements. This certified compliance makes it easy to pass EU customs and procurement audits for overseas projects.
The passage frame is built from 304 stainless steel or 201 stainless steel with baked paint, providing strong corrosion resistance and a long service life of more than 5 million operations.
With IP43 and IP54 rated protection the barrier works reliably both indoors and outdoors, resisting dust and water splashes in demanding entrance environments.
Six pairs of high precision infrared sensors monitor the channel in real time to detect pedestrians accurately and prevent the wings from closing on people, keeping every passage safe.
The opening time is only 0.5 seconds and the traffic speed reaches 30 people per minute, or 40 people per minute in normally open mode, ensuring smooth pedestrian flow at busy entrances.
The barrier supports RFID/IC/ID cards, fingerprint, QR code, NFC and face recognition, and provides relay, 12V level and RS485 or TCP/IP interfaces for easy integration with existing access control systems.
Working within an ambient temperature range of -30 C to 70 C and a relative humidity of no more than 95%, the turnstile delivers stable, certified performance in a wide range of environments.
| Product Name | Wing Gate |
| Barrier Material | Acrylic Swing Arm |
| Passage Frame | 304 Stainless Steel / 201 Stainless Steel With Baked Paint |
| Product Size | 1500mm*300mm*1000mm (Sizes Can Be Customized) |
| Traffic Speed | 30 People/Minute, Normally Open 40 People/Minute |
| Service Life | ≥5 Million Times |
| Channel Width | 550-600mm |
| Weight | 50-85KG |
| LED indicator | 2 pieces |
| Working Voltage | AC220V±10%/50HZ 50W |
| Relative Temperature | ≤95% Not Condensing |
| Product Power | 100W |
| Opening Time | 0.5 Seconds |
| Ambient Temperature | -30℃-70℃ |
| Work Environment | Indoor And Outdoor |
| Protection Grade | IP43, IP54 |
| Infrared Sensor | 6 Pairs |
| Access Control Type | RFID/IC/ID card. Face/Iris recognition/Fingerprint identification.QR code. Mobile phone/NFC. Password. Remote door opening |
| Communication Interface | Relay switch signal/12V level signal/12V pulse signal with pulse width＞100ms; RS485 or TCP/IP |
Yes. The turnstile is CE certified and RoHS compliant, meeting the safety, EMC and hazardous substance requirements of the European market for smooth EU customs clearance.
The passage frame is made of 304 stainless steel or 201 stainless steel with baked paint, offering strong corrosion resistance and a service life of more than 5 million operations.
Yes. With IP43 and IP54 protection grades the barrier is suitable for both indoor and outdoor environments, and its -30 C to 70 C working range ensures stable operation.
It supports RFID/IC/ID cards, fingerprint, QR code, NFC and face recognition, and offers relay, 12V level and RS485 or TCP/IP interfaces for flexible system integration.
Yes. CE and RoHS certificates and related test reports are available for importing and project auditing. Contact us for the complete document package.
Yes. The standard size is 1500mm*300mm*1000mm with a 550-600mm channel width, and both the size and channel width can be customized to your project requirements.
Looking for a CE certified wing barrier turnstile supplier for your project? Contact us today for competitive factory pricing, CE and RoHS certification documents, customized solutions, installation guidance and technical support.
