Indoor Playground Speed Gate Turnstile Wristband QR Code Time Control Session Extension

Indoor Playground Speed Gate Turnstile  Wristband QR Code Time Control Session Extension

Product Overview

This Indoor Playground Speed Gate Turnstile is designed for indoor playgrounds , trampoline parks , soft play centres , family entertainment centres and children ' s museums , where entry is sold by play session and the operator has to know exactly how many children are inside at any minute .

Two problems repeat in every such venue . Time limit control fails : a family buys a two hour session and stays all afternoon , so the next time slot cannot enter and the front desk ends up arguing with parents . Manual ticket checking also collapses at peak times : one staff member tears stubs or scans phones at the entrance , a queue forms , children run ahead and parents lose patience .

The lane replaces both jobs with a wristband QR code . Timing starts automatically the moment the wristband is scanned at entry , the remaining time is visible to the operator , and when the session expires the swing arm blocks further passage . An overtime top up rule allows the guest to buy a supplement at the front desk or a self service kiosk and pass again , so the venue keeps the revenue instead of arguing about it . Guests scan their own code with no staff involvement , and the backend shows live occupancy , entry time , exit time and remaining time for every wristband .

The cabinet is 1200*200*1000mm in 304 stainless steel with an acrylic swing arm , six pairs of infrared sensors and an 80W drive that opens in 0.5 seconds at 30 people per minute , or 40 people per minute in normally open mode . The mechanism is rated for at least 5 million cycles with IP43 or IP54 protection , and the anti pinch rebound force stays below 2 Kg so a child is never trapped or hurt .

Product Advantages

1 . Wristband QR code time control

Timing starts from the first scan , not from the cash desk , so the session is measured from the moment the child actually enters . Remaining time is tracked per wristband and the lane blocks passage automatically on expiry , which ends the overtime dispute and protects the capacity of the next time slot .

2 . Overtime top up rule

Instead of releasing the gate manually , the operator sets a top up rule : the guest buys a supplement ticket at the front desk or a self service kiosk and the wristband becomes valid again for the extra period . Revenue is captured and every extension is logged against the same wristband .

3 . Self service passage without ticket checking

Guests scan their own QR code and walk through , so one attendant can supervise several lanes and the entrance keeps moving during weekend and holiday peaks . No torn stubs , no shared phones at the desk , and no queue that pushes parents out of the door .

4 . Live occupancy and ticketing dashboard

Entry time , exit time and remaining time are synchronised to the backend in real time , so the manager can see how many people are inside , which sessions are full and how top ups perform , from a computer or phone at any moment . This data supports staffing and session scheduling decisions .

5 . Membership and multi modal expansion

Beyond wristband QR code , the controller supports facial recognition , fingerprint , IC / ID card , password , mobile phone NFC and palm print , so a venue can add annual passes , member face entry or a loyalty account on the same lane without replacing hardware .

6 . Child safe anti-pinch and emergency release

When the acrylic swing arm meets resistance it rebounds immediately or the motor stops , with impact force not exceeding 2 Kg , protecting children who run back through the lane . On power failure or fire alarm the gate sounds an alarm and opens automatically for evacuation , then resumes normal control when power returns .

7 . Easy maintenance and quiet operation

The built in self diagnosis module raises an alarm on a sensor , motor or controller fault , and the operating mode is programmed on site with the keypad on the main control board . The 80W drive opens in 0.5 seconds with low noise , which suits a venue where music , announcements and children are already loud .

Technical Specifications

FAQ

1 . What is the minimum order quantity of this indoor playground speed gate ?

The minimum order quantity is 1 pcs , which suits a single entrance lane , a member channel or a pilot installation before a full venue rollout .

2 . How does the wristband time control work in practice ?

The wristband QR code is scanned at entry and the session timer starts at that moment . Remaining time is recorded per wristband , and when the session expires the lane blocks passage until a top up ticket is purchased .

3 . Can guests extend their session without calling staff ?

Yes . With the overtime top up rule enabled , the guest buys a supplement ticket at the front desk or a self service kiosk and the same wristband becomes valid again for the extra period , with the extension logged automatically .

4 . Can it work with our existing ticketing or membership system ?

Yes . The controller accepts relay , 12V level and 12V pulse signals and communicates over RS485 or TCP/IP , so wristband , QR code and member data can be exchanged with a ticketing platform , POS or membership system .

5 . Is the gate safe for small children ?

The anti pinch mechanism rebounds with a force not exceeding 2 Kg , the passage is monitored by six pairs of infrared sensors , and on power failure or fire alarm the gate opens automatically for evacuation .

6 . What are the delivery time , packing and warranty terms ?

Stock units ship in 5 days and production orders in 5 to 14 work days , each lane is packed in a wooden case , and the drive and controller carry a 12 month warranty with spare parts and remote technical support .
